| Place of Origin: | China |
|---|---|
| Brand Name: | Caterpillar |
| Certification: | 68555435543 |
| Model Number: | D8N, D8R, D8R |
| Minimum Order Quantity: | 1 |
| Price: | Price negotiation |
| Packaging Details: | box |
| Delivery Time: | 3-5 |
| Payment Terms: | T/T, L/C, Western Union |
| Supply Ability: | 10 |
| Model OEM: | D8N, D8R, D8R | Product Name: | 9T8346 PUMP GP-PISTON Caterpillar Parts |
|---|---|---|---|
| Cross Code: | CA9T8346 9T-8346 9T8346 | Other Name: | Piston Kit |
| Sort: | Cylinder Liner | Application: | Engine Parts |
| Applicable: | Excavator Parts | Weight: | XX Kg. |
9T8346 PUMP GP-PISTON Caterpillar parts D8N, D8R, D8R
Product Description
CA9T8346
9T-8346
9T8346
Caterpillar SIS
TRACK-TYPE TRACTOR D8N D8R D8R II Caterpillar
9T-8346 PUMP GP-PISTON
S/N 7XM1-UP
PART OF 136-7375 LINES GP-SCRAPER
Information
| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 6E-4248 | [1] | SHAFT | |
| 2. | 6E-4237 | [1] | BEARING | |
| 3. | 6E-4224 | [1] | PLUG-SWASHPLATE | |
| 4. | 033-6036 | [1] | SEAL-O-RING | |
| 5. | 9S-4190 | [1] | PLUG-O-RING (7/8-14-THD) | |
| 6. | 9T-1699 | [1] | SPRING | |
| 7. | 9T-1710 | [1] | POPPET | |
| 8. | 9T-1636 | [1] | SEAT | |
| 9. | 6E-4227 | [1] | COVER | |
| 10. | 6V-8837 M | [3] | BOLT (M6X1X16-MM) | |
| 11. | 4F-4097 | [1] | SEAL-O-RING | |
| 12. | 6E-4236 | [1] | BEARING | |
| 13. | 3E-4302 M | [2] | SCREW-FLAT HEAD (M4X0.7X10-MM) | |
| 14. | 8T-5039 | [3] | SEAL-O-RING | |
| 15. | 4H-1440 | [2] | PIN-SPRING | |
| 16. | 8T-0343 M | [3] | BOLT-SOCKET HEAD (M12X1.75X55-MM) | |
| 17. | 3E-8008 M | [1] | BOLT-SOCKET HEAD (M16X2X90-MM) | |
| 18. | 6E-6044 Y | [1] | VALVE GP-PUMP CONTROL (PRESSURE, FLOW COMPENSATOR)(IMPLEMENT PUMP OUTLET CONTROL) | |
| 19. | 6E-4245 | [1] | HOUSING | |
| 20. | 6V-8337 M | [4] | BOLT-SOCKET HEAD (M8X1.25X35-MM) | |
| 21. | 033-6027 | [1] | SEAL-O-RING | |
| 22. | 7K-8876 | [1] | CUP-BEARING | |
| 23. | 6E-4213 | [1] | KIT-BIAS PISTON (PUMP) | |
| (INCLUDES SPRING, ROD, PISTON & PACKING) | ||||
| 24. | 6E-4214 | [1] | SPRING-BIAS | |
| 25. | 6E-4216 Y | [1] | ROTATING GP-PUMP (IMPLEMENT) | |
| 26. | 6E-4225 | [1] | GASKET | |
| 27. | 7L-9061 | [2] | SEAL-O-RING | |
| 28. | 3E-7417 | [4] | PLUG | |
| 29. | 8T-7876 | [4] | SEAL-O-RING | |
| 30. | 6E-4234 | [1] | PLATE-VALVE | |
| 31. | 005-0471 | [1] | CONE-BEARING | |
| 32. | 005-0469 | [1] | CUP-BEARING | |
| 33. | 103-6282 B | [1] | SHIM PACK (INCLUDES 17-SHIMS) | |
| 34. | 9T-1652 | [1] | PIN | |
| 35. | 6E-4215 | [1] | KIT-PISTON (PUMP) | |
| (INCLUDES PACKING, ROD & PISTON) | ||||
| 36. | 6E-4221 Y | [1] | SWASHPLATE GP | |
| 37. | 6L-8797 | [2] | RING-RETAINING | |
| 38. | 9X-7547 | [2] | SEAL-LIP TYPE | |
| 39. | 7K-8877 | [1] | CONE-BEARING | |
| 40. | 6E-4247 | [1] | HEAD | |
| 41. | 6E-2943 | [1] | PLUG | |
| 42. | 6E-4321 | [1] | SPACER (36X48X2.5-MM THK) | |
| 43. | 3E-8007 M | [1] | BOLT-SOCKET HEAD (M12X1.75X90-MM) | |
| 44. | 219-6915 | [1] | BOLT (M16X2X95-MM) | |
| 1915603 Piston | Engine | 191-5603 | Ring | 9T8647 Pump Group Piston | Cylinder Liner | 9T-8647 |
| 1915709 Piston | Engine | 191-5709 | Ring | 9T9912 Pump Group Piston | Cylinder Liner | 9T-9912 |
| 1922209 Body A | Engine | 192-2209 | Ring | 9T9912 Pump Group Piston | Cylinder Liner | 9T-9912 |
| 1979335 Pin As | Engine | 197-9335 | Ring | Rs3406E1 Ring Set Piston | Cylinder Liner | 34-0600 |
| 1990706 Piston | Engine | 199-0706 | Ring | Rs3406E2 Ring Set Piston | Cylinder Liner | 34-0600 |
| 2131152 Piston | Engine | 213-1152 | Ring | Rs4P2654 Ring Set Piston | Cylinder Liner | 4P-2654 |
| 2179778 Piston | Engine | 217-9778 | Ring | Rs4P8996 Ring Set Piston | Cylinder Liner | 4P-8996 |
| 2254284 Piston | Engine | 225-4284 | Ring | Rs7E3888 Ring Set Piston | Cylinder Liner | 7E-3888 |
| 2264961 Piston | Engine | 226-4961 | Ring | Tak2874 Piston Liner Kit | Cylinder Liner | Tak-2874 |
| 2289572 Piston | Engine | 228-9572 | Ring | Tak3102 Piston Liner Kit | Cylinder Liner | Tak-3102 |
| 2332582 Piston | Engine | 233-2582 | Ring | Tak3633 Piston Liner Kit | Cylinder Liner | Tak-3633 |
| 2344814 Piston | Engine | 234-4814 | Ring | Tak4262 Piston Liner Kit | Cylinder Liner | Tak-4262 |
| 2382729 Body A | Engine | 238-2729 | Ring | Tak4515 Piston Liner Kit | Cylinder Liner | Tak-4515 |
