| Place of Origin: | China |
|---|---|
| Brand Name: | Caterpillar |
| Certification: | 68555435543 |
| Model Number: | D6H, D6H II, D6H XL, D6H XR, D6R |
| Minimum Order Quantity: | 1 |
| Price: | Price negotiation |
| Packaging Details: | box |
| Delivery Time: | 3-5 |
| Payment Terms: | T/T, L/C, Western Union |
| Supply Ability: | 10 |
| Model OEM: | D6H, D6H II, D6H XL, D6H XR, D6R | Product Name: | 9T3680 PUMP GP-PISTON Caterpillar Parts |
|---|---|---|---|
| Cross Code: | CA9T3680 9T-3680 9T3680 | Other Name: | Piston Kit |
| Sort: | Cylinder Liner | Application: | Engine Parts |
| Applicable: | Excavator Parts | Weight: | XX Kg. |
9T3680 PUMP GP-PISTON Caterpillar parts D6H, D6H II, D6H XL, D6H XR, D6R
Product Description
CA9T3680
9T-3680
9T3680
TRACK-TYPE TRACTOR D6H D6H II D6H XL D6H XR D6R Caterpillar
Caterpillar SIS
9T3680 PUMP GP-PISTON*X
SLIPPER
PART OF 9T7099 PUMP-PISTON & GEAR
Information
| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 7X-2439 | [1] | RING-RETAINING | |
| 2. | 7X-1553 | [1] | SEAL-LIP TYPE | |
| 3. | 9T-7738 | [1] | HOUSING | |
| 4. | 9T-8096 | [1] | RACE | |
| 5. | 6V-8797 | [1] | CUP-ROLLER BEARING | |
| 6V-8796 | [1] | CONE-ROLLER BEARING | ||
| 6. | 9T-8104 | [1] | SHAFT | |
| 7. | 6V-7951 | [1] | DOWEL | |
| 8. | 9T-7708 | [2] | PLUG | |
| 9. | 9T-8105 | [1] | SUPPORT | |
| 10. | 9T-5039 | [1] | PLUG | |
| 11. | 9T-8106 | [1] | SWASHPLATE | |
| 12. | 9T-7725 | [1] | PISTON AS | |
| 13. | 9T-7724 | [1] | RING | |
| 14. | 9T-8113 | [1] | PLUG | |
| 15. | 9T-8108 | [1] | HEAD GP-PUMP | |
| 9T-8107 | [1] | BUSHING | ||
| 9T-8109 | [1] | BUSHING | ||
| 16. | 9S-8004 | [1] | PLUG-O-RING | |
| 17. | 3J-1907 | [3] | SEAL | |
| 18. | 9T-7711 M | [15] | PLUG-PIPE | |
| 19. | 5P-8245 | [8] | WASHER | |
| 20. | 6V-8149 M | [8] | NUT | |
| 21. | 9T-8093 | [1] | SPRING | |
| 22. | 9T-8428 | [1] | SETSCREW | |
| 23. | 9T-8094 | [1] | SPRING | |
| 24. | 9T-7722 | [1] | RING | |
| 25. | 9T-8110 | [1] | RETAINER | |
| 26. | 9X-6378 | [1] | RING-RETAINING | |
| 27. | 9T-8442 | [1] | PISTON AS | |
| 28. | 9T-8443 | [1] | PISTON AS | |
| 29. | 9T-7731 | [9] | PISTON AS | |
| 30. | 9T-7730 | [1] | PLATE AS | |
| 31. | 9T-7588 | [3] | BEARING | |
| 32. | 9T-7729 | [1] | BARREL AS | |
| 33. | 9T-7714 | [1] | SPACER | |
| 34. | 9T-7728 | [1] | SPRING | |
| 35. | 9T-7716 | [1] | SPACER | |
| 36. | 9T-8112 | [1] | SHIM | |
| 37. | 9T-4906 | [1] | RING-RETAINING | |
| 38. | 9T-8114 | [1] | WASHER | |
| 39. | 9T-7736 | [1] | PIN | |
| 40. | 8T-5395 M | [2] | SETSCREW-HEAD | |
| 41. | 9T-7720 M | [2] | NUT | |
| 42. | 9S-8006 | [2] | PLUG-O-RING | |
| 2M-9780 | [2] | SEAL-O-RING | ||
| 43. | 8C-8729 M | [1] | BOLT-SOCKET HEAD | |
| 44. | 2Y-6458 | [1] | GASKET | |
| 45. | 7X-2436 M | [8] | BOLT-HEX HEAD | |
| 46. | 8T-4231 | [1] | DOWEL | |
| 47. | 9T-7727 | [1] | PLATE | |
| 48. | 9T-7732 B | [1] | SHIM (.5MM THK) | |
| 9T-7733 B | [1] | SHIM (.7MM THK) | ||
| 9T-7734 B | [1] | SHIM (.8MM THK) | ||
| 9T-7735 B | [1] | SHIM (.6MM THK) | ||
| 49. | 6Y-2737 | [1] | CUP-ROLLER BEARING | |
| 6Y-2736 | [1] | CONE-ROLLER BEARING | ||
| 50. | 9T-4140 | [1] | PLUG | |
| 51. | 6V-9178 | [2] | SEAL-O-RING | |
| 52. | 9T-6318 | [2] | SPRING-BELLVILLE | |
| 53. | 9T-8097 | [1] | PLUG | |
| 54. | 8T-9528 | [2] | SEAL-O-RING | |
| 55. | 4D-5256 | [1] | SEAL-O-RING | |
| 56. | 9T-8115 | [1] | BUSHING | |
| 57. | 9T-4060 | [1] | SEAL-O-RING | |
| 58. | 9T-4189 | [1] | SPRING-CONTROL | |
| 59. | 9T-4185 | [1] | SPRING-CONTROL | |
| 60. | 9T-4130 | [1] | RETAINER-SPRING | |
| 61. | 9T-8116 | [1] | PLUG | |
| 62. | 9T-8429 | [1] | SETSCREW | |
| 63. | 9T-8098 | [2] | NUT | |
| 64. | 9T-4818 | [1] | PLUG | |
| 65. | 9T-4143 | [1] | PISTON-PRESSURE | |
| 66. | 9T-8111 | [1] | HOUSING AS | |
| 67. | 6V-5195 M | [2] | BOLT-SOCKET HEAD | |
| 68. | 9S-4191 | [2] | PLUG-O-RING | |
| 69. | 8T-9535 M | [2] | BOLT-SOCKET HEAD | |
| 70. | 9T-4141 | [2] | RETAINER-SPRING | |
| 71. | 9T-4186 | [1] | SPRING-CONTROL | |
| 72. | 5P-9658 | [1] | SEAL-O-RING |
| 1308412 Piston | Engine | 130-8412 | Ring | 7E5214 Ring Group Piston | Cylinder Liner | 7E-5214 |
| 1589064 Piston | Engine | 158-9064 | Ring | 7N9805 Pin Hollow Piston | Cylinder Liner | 7N-9805 |
| 1590308 Piston | Engine | 159-0308 | Ring | 8J6730 Pump Group Piston | Cylinder Liner | 8J-6730 |
| 1606600 Piston | Engine | 160-6600 | Ring | 8N0822 Ring Group Piston | Cylinder Liner | 8N-0822 |
| 1607994 Body A | Engine | 160-7994 | Ring | 9R9408 Piston Rear Brake | Cylinder Liner | 9R-9408 |
| 1656969 Piston | Engine | 165-6969 | Ring | 9R9408 Piston Rear Brake | Cylinder Liner | 9R-9408 |
| 1684531 Body A | Engine | 168-4531 | Ring | 9T2306 Pump Group Piston | Cylinder Liner | 9T-2306 |
| 1684538 Tube A | Engine | 168-4538 | Ring | 9T2306 Pump Group Piston | Cylinder Liner | 9T-2306 |
| 1692969 Piston | Engine | 169-2969 | Ring | 9T3680 Pump Group Piston | Cylinder Liner | 9T-3680 |
| 1722353 Piston | Engine | 172-2353 | Ring | 9T3680 Pump Group Piston | Cylinder Liner | 9T-3680 |
| 1769273 Piston | Engine | 176-9273 | Ring | 9T6857 Pump Group Piston | Cylinder Liner | 9T-6857 |
| 1786546 Piston | Engine | 178-6546 | Ring | 9T6857 Pump Group Piston | Cylinder Liner | 9T-6857 |
| 1850232 Piston | Engine | 185-0232 | Ring | 9T8346 Pump Group Piston | Cylinder Liner | 9T-8346 |
