| Place of Origin: | China |
|---|---|
| Brand Name: | Caterpillar |
| Certification: | 68555435543 |
| Model Number: | D6M |
| Minimum Order Quantity: | 1 |
| Price: | Price negotiation |
| Packaging Details: | box |
| Delivery Time: | 3-5 |
| Payment Terms: | T/T, L/C, Western Union |
| Supply Ability: | 10 |
| Model OEM: | D6M | Product Name: | 1078136 PUMP GP-PISTON Caterpillar Parts |
|---|---|---|---|
| Cross Code: | CA1078136 107-8136 1078136 | Other Name: | Piston Kit |
| Sort: | Cylinder Liner | Application: | Engine Parts |
| Applicable: | Excavator Parts | Weight: | XX Kg. |
1078136 PUMP GP-PISTON Caterpillar parts D6M
Product Description
CA1078136
107-8136
1078136
TRACK-TYPE TRACTOR D6M Caterpillar
Caterpillar SIS
107-8136 PUMP GP-PISTON -IMPLEMENT
S/N 9ZM1-UP; 2RN1-UP
SLIPPER
PART OF 107-4113 LINES GP-PUMP
Information
| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 6E-6572 | [1] | SHAFT | |
| 2. | 6E-6573 | [1] | BEARING | |
| 3. | 6E-4224 | [1] | PLUG-SWASHPLATE | |
| 4. | 033-6036 | [1] | SEAL-O-RING | |
| 5. | 109-4198 | [1] | HEAD-PUMP | |
| 6. | 9T-1699 | [1] | SPRING | |
| 7. | 9T-1710 | [1] | POPPET | |
| 8. | 9T-1636 | [1] | SEAT | |
| 9. | 6E-6575 | [1] | COVER | |
| 10. | 6V-8837 M | [3] | BOLT (M6X1X16-MM) | |
| 11. | 1P-8362 | [1] | SEAL-O-RING | |
| 12. | 6E-6576 | [1] | BEARING | |
| 13. | 3E-4302 M | [2] | SCREW-FLAT HEAD (M4X0.7X10-MM) | |
| 14. | 6E-2943 | [1] | PLUG | |
| 15. | 095-0888 | [2] | PIN-SPRING | |
| 16. | 9T-3038 | [1] | SHIM PACK (INCLUDES 17 SHIMS) | |
| 17. | 6V-5684 M | [4] | BOLT (M12X1.75X45-MM) | |
| 18. | 9S-4185 | [1] | PLUG (3/4-16-THD) | |
| 19. | 3K-0360 | [1] | SEAL-O-RING | |
| 20. | 100-2812 Y | [1] | VALVE GP-PUMP CONTROL (PRESSURE, FLOW COMPENSATOR) | |
| 21. | 6V-8336 M | [1] | BOLT (M12X1.75X70-MM) | |
| 22. | 8T-5039 | [3] | SEAL-O-RING | |
| 23. | 6V-8337 M | [4] | BOLT-SOCKET HEAD (M8X1.25X35-MM) | |
| 24. | 6E-6577 | [1] | HOUSING | |
| 25. | 005-0469 | [1] | CUP-BEARING | |
| 26. | 6E-6578 | [1] | KIT-PISTON BIAS | |
| (INCLUDES SPRING, ROD, PISTON, & SEAL) | ||||
| 27. | 6E-6579 | [1] | SPRING-BIAS | |
| 28. | 6E-6569 Y | [1] | ROTATING GP-PUMP | |
| 29. | 6E-6580 | [1] | GASKET | |
| 30. | 6V-3922 | [2] | SEAL-O-RING | |
| 31. | 3E-7417 | [2] | PLUG | |
| 32. | 8T-7876 | [2] | SEAL-O-RING | |
| 33. | 9T-3030 | [1] | PLATE | |
| 34. | 111-6800 | [1] | CONE-BEARING | |
| 35. | 111-6801 | [1] | CUP-BEARING | |
| 36. | 8T-0372 M | [1] | BOLT (M12X1.75X90-MM) | |
| 37. | 9T-1652 | [1] | PIN | |
| 38. | 6E-6582 | [1] | KIT-PISTON CONTROL | |
| 39. | 6E-6583 | [1] | SWASHPLATE GP | |
| 8F-7219 | [2] | SEAL-O-RING | ||
| 139-0532 | [2] | BLOCK-STOP | ||
| 40. | 008-3214 | [2] | RING-RETAINING (INTERNAL) | |
| 41. | 3E-6776 | [2] | SEAL-LIP TYPE | |
| 42. | 005-0471 | [1] | CONE-BEARING | |
| Engine | 188-4216 | Ring | 9T8346 Pump Group Piston | Cylinder Liner | 9T-8346 |
| Engine | 190-2279 | Ring | 9T8647 Pump Group Piston | Cylinder Liner | 9T-8647 |
| Engine | 191-5603 | Ring | 9T8647 Pump Group Piston | Cylinder Liner | 9T-8647 |
| Engine | 191-5709 | Ring | 9T9912 Pump Group Piston | Cylinder Liner | 9T-9912 |
| Engine | 192-2209 | Ring | 9T9912 Pump Group Piston | Cylinder Liner | 9T-9912 |
| Engine | 197-9335 | Ring | Rs3406E1 Ring Set Piston | Cylinder Liner | 34-0600 |
| Engine | 199-0706 | Ring | Rs3406E2 Ring Set Piston | Cylinder Liner | 34-0600 |
| Engine | 213-1152 | Ring | Rs4P2654 Ring Set Piston | Cylinder Liner | 4P-2654 |
| Engine | 217-9778 | Ring | Rs4P8996 Ring Set Piston | Cylinder Liner | 4P-8996 |
| Engine | 225-4284 | Ring | Rs7E3888 Ring Set Piston | Cylinder Liner | 7E-3888 |
| Engine | 226-4961 | Ring | Tak2874 Piston Liner Kit | Cylinder Liner | Tak-2874 |
| Engine | 228-9572 | Ring | Tak3102 Piston Liner Kit | Cylinder Liner | Tak-3102 |
| Engine | 233-2582 | Ring | Tak3633 Piston Liner Kit | Cylinder Liner | Tak-3633 |
